AUTOMATIC TRANSAXLE (M13 ENGINE) 7B1-27
Automatic Transaxle Basic Check
This check is important for troubleshooting when TCM has detected no DTC and no abnormality has been noted
in visual inspection. Follow the flow table carefully.
Step Action Yes No
1Was “Automatic Transaxle Diagnostic Flow
Tabl e ” preformed?
Go to Step 2. Go to “Automatic Tran-
saxle Diagnostic Flow
Ta bl e ”.
2Perform “Road Test” in this section.
Is it OK?
Go to Step 3. Proceed to “Trou bl e -
shooting” in “Road Test”.
3Perform “Manual Road Test” in this section.
Is it OK?
Go to Step 4. Proceed to “Trou bl e -
shooting” in “Manual
Road Test”.
4Perform “Engine Brake Test” in this section.
Is it OK?
Go to Step 5. Proceed to “Trou bl e -
shooting” in “Engine
Brake Test”.
5Perform “Stall Test” in this section.
Is it OK?
Go to Step 6. Proceed to “Trou bl e -
shooting” in “Stall Test”.
6Perform “Time Lag Test” in this section.
Is it OK?
Go to Step 7. Proceed to “Trou bl e -
shooting” in “Time Lag
Te st ”.
7Perform “Line Pressure Test” in this section.
Is it OK?
Go to Step 8. Proceed to “Trou bl e -
shooting” in “Line Pres-
sure Test”.
8 Proceed to “Trouble Diagnosis Table-1” in this
section.
Is trouble identified?
Repair or replace faulty
parts.
Go to Step 9.
9 Proceed to “Trouble Diagnosis Table-2” in this
section.
Is trouble identified?
Repair or replace faulty
parts.
Proceed to “Trouble Diag-
nosis Table-3” in this sec-
tion.
