9-4 BODY SERVICE
Exterior and Interior Trim
Back Door Emblem
Back door emblem dimension
Position
Dimension
Position
Dimension
mm in mm in
a 568 22.36 g 40 1.57
b 76 2.99 h 2 0.08
c 69 2.72 i 9 0.35
d 574 22.6 j 9 0.35
e 74.5 2.93 k 9 0.35
f74 2.91
