6-2-18 ENGINE GENERAL INFORMATION AND DIAGNOSIS (M13 ENGINE)
P1601 CAN communication error Transmitting or receiving error detected to ECM for
specified time continuously.
1 driving
cycle
P1603 TCM trouble code detected When ECM receives a trouble code from TCM, which
indicates that some problem occurred in sensor circuits
and its calculated values used for operations such as
idle speed control, engine power control, and so on by
TCM, this DTC is detected by ECM.
1 driving
cycle
P2227 Barometric pressure circuit
range/performance
Difference between barometric pressure sensor value
and calculated barometric pressure value is larger than
specification.
2 driving
cycles
P2228 Barometric pressure circuit
low
Barometric pressure sensor circuit shorted to ground. 1 driving
cycle
P2229 Barometric pressure circuit
high
Barometric pressure sensor circuit open 1 driving
cycle
P1610 Secret key and password not
registered
Refer to “DTC Table” in Section 8G
P1611 Password not matched
P1612 No signal from immobilizer
P1613
P1614 Incorrect signal
DTC
NO.
DETECTING ITEM DETECTING CONDITION
(DTC will set when detecting:)
MIL
NOTE:
• 1 driving cycle: MIL lights up when DTC is detected while 1 driving cycle.
• 2 driving cycles: MIL lights up when the same DTC is detected also in the next driving cycle after
DTC is detected and stored temporarily in the first driving cycle.
•
✱
2 driving cycles:
MIL blinks or lights up. Refer to “DTC P0300/P0301/P0302/P0303/P0304: Random Misfire/Cylinder 1
Misfire/Cylinder 2 Misfire/Cylinder 3 Misfire/Cylinder 4 Misfire Detected” for details.
