AUTOMATIC TRANSAXLE (M13 ENGINE) 7B1-35
3
→
O/D upshift fails to
occur
Malfunction of shift solenoid valve-B
Inspect. If NG, replace.
Malfunction of O/D off switch
Malfunction of engine coolant temperature sen-
sor
Malfunction of output shaft speed sensor (VSS)
Malfunction of input shaft speed sensor
Malfunction of throttle position sensor
Malfunction of transmission range sensor
Malfunction of crankshaft position sensor
Malfunction of timing solenoid valve
Malfunction of transmission fluid temperature
sensor
Malfunction of pressure control solenoid valve
Inspect. If NG, replace valve body
assembly.
Faulty valve body component Replace valve body assembly.
Faulty O/D and 2nd coast brake Inspect. If NG, replace.
O/D
→
3 downshift fails
to occur
Malfunction of shift solenoid valve-A
Inspect. If NG, replace.
Malfunction of O/D off switch
Malfunction of output shaft speed sensor (VSS)
Malfunction of input shaft speed sensor
Malfunction of throttle position sensor
Malfunction of timing solenoid valve
Malfunction of pressure control solenoid valve
Inspect. If NG, replace valve body
assembly.
Faulty valve body component Replace valve body assembly.
Faulty forward clutch Inspect. If NG, replace.
3
→
2 downshift fails to
occur
Malfunction of shift solenoid valve-A
Inspect. If NG, replace.Malfunction of output shaft speed sensor (VSS)
Malfunction of throttle position sensor
Faulty valve body component Replace valve body assembly.
Faulty one-way No.1 clutch Inspect. If NG, replace.
2
→
1 downshift fails to
occur
Malfunction of shift solenoid valve-B
Inspect. If NG, replace.Malfunction of output shaft speed sensor (VSS)
Malfunction of throttle position sensor
Faulty valve body component Replace valve body assembly.
Faulty one-way No.2 clutch Inspect. If NG, replace.
Gear shift point is incor-
rect
Abnormal engine condition Inspect and repair engine.
Malfunction of output shaft speed sensor (VSS)
Inspect. If NG, replace.
Malfunction of throttle position sensor
Malfunction of pressure control solenoid valve
Inspect. If NG, replace valve body
assembly.
Condition Possible Cause Correction
