7B1-84 AUTOMATIC TRANSAXLE (M13 ENGINE)
TIMING SOLE-
NOID MONITOR
Ignition switch ON and selector lever is in “N” range OFF
For about 0.5 sec. while on gear shifting between 3rd
and 4th or gear shifting N to D
ON
TCC SOLENOID
COMMAND
At 5 km/h (3 mile/h) constant speed, O/D off switch
ON, closed throttle and 1st gear
OFF
At 100 km/h (62.5 mile/h) constant speed, O/D off
switch OFF, 20% or less throttle opening and 4th gear
ON
TCC SOLENOID
COMMAND
At 5 km/h (3 mile/h) constant speed, O/D off switch
ON, closed throttle and 1st gear
OFF
At 100 km/h (62.5 mile/h) constant speed, O/D off
switch OFF, 20% or less throttle opening and 4th gear
ON
PRESSURE CON-
TROL SOLENOID
At vehicle stop, closed throttle, engine idle speed and
1st gear
0%
VEHICLE SPEED At vehicle stop 0 KM/H, 0 MPH
O/D OFF SWITCH Ignition switch ON O/D off switch OFF OFF
O/D off switch ON ON
TRANSAXLE Ignition switch ON Selector lever is in “P” position P
Selector lever is in “R” position R
Selector lever is in “N” position N
Selector lever is in “D” position D
Selector lever is in “2” position 2
Selector lever is in “L” position L
D RANGE SIGNAL Ignition switch ON Selector lever is in “P” position OFF
Selector lever is in “R” position ON
Selector lever is in “N” position OFF
Selector lever is in “D” position ON
Selector lever is in “2” position ON
Selector lever is in “L” position ON
THROTTLE POSI-
TOIN
Ignition switch ON Accelerator pedal is released 0%
Accelerator pedal is depressed 0 – 100%
(Varies depending on depressed
value)
BRAKE SWITCH Ignition switch ON Brake pedal is depressed ON
Brake pedal is released OFF
TORQUE REDUC-
TION SIGNAL
While on gear upshifting with 25% or more throttle
opening
ON
Under condition of not shifting gear OFF
ENGINE COOL-
ANT TEMPERA-
TURE
Ignition switch ON Engine coolant temperature is
displayed
AIR CONDI-
TIONER SIGNAL
Ignition switch ON and air conditioner switch OFF OFF
ENGINE TORQUE
SIGNAL
Ignition switch ON and engine stop 0 N·m
SCAN TOOL DATA VEHICLE CONDITION
NORMAL CONDITION/REFER-
ENCE VALUES
