AUTOMATIC TRANSAXLE (M13 ENGINE) 7B1-127
18) Remove accumulator pistons and springs.
To remove C2 (1), C1 (2) and B1 (3) accumulator pistons
and springs, position rag on pistons to catch each piston. To
remove pistons, force low-pressure compressed air (1 kg/
cm
2
, 15 psi, 100 kPa, max) into hole (4) as shown in figure,
and pop each piston into rag.
19) Remove transaxle case plug (1).
20) Remove torque converter housing bolts.
21) Remove torque converter housing (1) while tapping around it
lightly with plastic hammer.
NOTE:
Do not push accumulator pistons with fingers or any-
thing before removing them. Pushing them may cause
compressed fluid in accumulator to spew out of hole and
get to your face and clothes.
