AUTOMATIC TRANSAXLE (M13 ENGINE) 7B1-133
44) Remove planetary gear thrust bearing (1).
45) Remove one-way clutch No.1 assembly (2) from rear plane-
tary sun gear subassembly (3).
46) Remove planetary carrier thrust washer (1).
47) Remove O/D and 2nd coast brake retaining plate snap ring
(1).
48) Remove front planetary sun gear (1).
49) Remove front sun gear thrust bearing race (2) from front
planetary sun gear (1).
NOTE:
If planetary gear thrust bearing is not found on one-way
clutch No.1 assembly, it may have been left in trasaxle.
