INSIGHT Software
The INSIGHT Window
Thermo Scientific Evolution 200 Series User Guide 13
Other task buttons may be available for specific applications:
Related Topics
Action Buttons
Other Navigation Pane Features
Action Buttons
These action buttons appear at the top of the navigation pane when appropriate for the
opened application:
Options Includes features for controlling how users interact with the software.
System Settings Provides features for aligning accessories, calibrating lamps, updating
firmware and performing other tasks.
If a Local Control instrument is connected to an external computer
running INSIGHT software, use the Instrument Control options on the
System tab to select the desired location of instrument control.
Button Description
Measure (current
application)
Displays data acquisition features for the current application.
Reports Configures reports containing sample data and specifies how to
print reports.
Oligo Calculator Calculates molecular weight, extinction coefficients, concentration
factors and melting points for nucleic acid sequences.
Dye/Chrom. Editor For entering and editing new dyes rather than using one of the
precoded default dyes.
Button Description
Button Description
Starts sample data acquisition, displaying prompts for confirming samples
information, loading samples, saving data or performing other actions. Available
only after a blank measurement for some applications. May measure single or
multiple samples, depending on the application settings.
Measures the baseline for the application.
