INSIGHT Software
The INSIGHT Window
18 Evolution 200 Series User Guide Thermo Scientific
Annotate Provides features for adding annotation to displayed data. (Added
annotation is displayed only for the selected data.) See Working
With Labels for information about manipulating added labels.
Right-click an edge of an added ellipse, rectangle or image to access
ways to manipulate or delete the object. The availability of features
depends on the current application.
More:
Attach to Curve displays the X value of the pointer location as a
label attached to a scan spectrum by a line.
Free Standing Text adds an editable label at the pointer location.
Its position is not affected by zooming in and out.
Ellipse draws an ellipse. To move it, drag its top edge. To resize it,
drag a side or bottom edge. Its position, size and shape are affected
by zooming in and out.
Rectangle draws a rectangle. To move it, drag its top edge. To
resize it, drag a side or bottom edge or a corner. Its position, size
and shape are affected by zooming in and out.
Image displays a dialog box for locating and selecting an image to
add to the display. To move the image, drag its top edge. To resize
it, drag the bottom edge or a corner. Its position and size are
affected by zooming in and out.
Floating Image works the same as Image (see above), except the
image position and size are not affected by zooming.
Tool Value displays the measurement made by the Peak/valley
measurement tool or peak area tool as a label attached to the
spectrum by a line.
Feature Description
