INSIGHT Software
The INSIGHT Window
Thermo Scientific Evolution 200 Series User Guide 19
Related Topics
Working With Labels
Measuring Samples
Right Pane
Measurement Results
The INSIGHT Window
Working With Labels
Some operations place labels on the displayed data. Here is an example:
More Display Options
(Fixed only)
Specifies how to display fixed sample data and control limits:
Connect points (in Spectrum) draws connecting lines between
sample points.
Show annotations displays X and Y values of sample points.
Show X grid draws light vertical lines through sample points,
making it easier to see their X values.
Show Y grid draws light horizontal lines through sample points,
making it easier to see their Y values.
If control limits were specified by Use control limits on the
Instrument tab, Show limit lines displays for each sample point
the triangular control limit markers.
If control limits were specified, Connect points (in Limit Lines)
draws connecting lines between the triangular control limit
markers.
Feature Description
