VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
90 02.9678.0010 F
Iris Assembly
21.9678.0270 Rev A
Refer to Figure 3-10
No. Item Qty. UM. Description
1 10.9678.0272 1 EA BULKHEAD, IRIS
2 10.9678.0273 1 EA MOTOR MOUNT, IRIS
3 10.9678.0274 1 EA APERTURE, IRIS
4 10.9678.0276 1 EA CRANK, IRIS
5 10.9678.0279 1 EA DIVERTER, GOBO AIR
6 10.9678.0280 1 EA ADJUSTABLE IRIS STOP (changed 09-17-03)
7 22.9678.0271 1 EA LINK ASSY, IRIS
7a - 53.6605.0004 1 EA STUD, 2-56 X 1.0" LG FULL THREAD STAINLESS STEEL
7b - 54.1217.0005 2 EA KWIK LINK, 2-56 SPRING STEEL
8 22.9678.0275 1 EA IRIS, 49MM OD
9 44.9678.0278 1 EA MOTOR, 17 .94" SHAFT 11.8MH 5.5OHM
10 53.5558.0125 2 EA SCREW, 8-32 X .125 " SET SS
11 53.6513.0042 3 EA SCREW, M2 X .4 X 4MM LG PFB METRIC
12 53.6530.0013 2 EA RIVET, 1/8"OD POP 0.328" AL CSK HD STL MNDRL
13 53.6558.0001 2 EA SCREW, 6-32 X 3/8" PPZ
14 53.6609.0500 3 EA SCREW, 6-32 X 1/2" LG PFZ
15 55.2211.0002 1 EA STANDOFF, 1/4 " RND 6-32 0.188"LG (changed 09-17-03)
16 55.6538.0005 4 EA WASHER, 0.250"OD 0.65"ID 0.015"THK TEFLON
