Vari Lite VL3000 - Enclosure Assembly Upper Enclosure Assembly

ENCLOSURE ASSEMBLY : UPPER ENCLOSURE ASSEMBLY
02.9678.0010 F 159
3
Enclosure Assembly
Upper Enclosure Assembly
21.9678.0800.01 Rev NN
21.9678.0801.01 Rev Y (VL3000 Quiet)
Refer to Figure 3-65 and Figure 3-66
No. Item Qty. UM. Description
1 04.9640.0374 1 EA LABEL, P.E. GROUND
2 04.9661.1218.01 1 EA LABEL, PATENT, VL2201 & VL2400 SERIES LUM.
3 04.9678.0040.01 1 EA LABEL, VL3000 COMPLIANCE
04.9678.0045 1 EA LABEL, VL3000 QUIET COMPLIANCE
4 06.6032.0009 1 EA CABLE MARKER TIE, WHITE 19 X 7
5 10.9661.1258 1 EA BRACKET, APS SIDE
6 10.9661.1358 1 EA AIR SEAL, DUCT
7 10.9678.0820 1 EA LANYARD, PAN TUBE
8 10.9686.0839 2 EA COVER, TOP
9 10.9686.0846 2 EA HANDLE, CAST ENCLOSURE
10 10.9678.0869 1 EA BRACKET, LVS
11 10.9678.0886 1 EA SPACER, PAN BEARING 0.235" THK
12 10.9678.0892 1 EA BUSHING, WIRE PROTECTION PAN
13 10.9678.1876 1 EA AIR DIST PLENUM, 1200W S W BALLAST P/S
14 12.9686.1236 2 EA MACHINED, COVER FRONT
15 12.9686.1238 2 EA MACHINED, COVER SIDE
16 12.9678.0842 1 EA AIR DUCT, UPPER ENCLOSURE MOD
17 12.9678.1862 1 EA SHIELDED BALLAST, CCI
18 21.9678.1254 1 EA ASSY, COVER - VENTILATION
21.9686.0840.02 1 EA ASSY, COVER - VENT, VL3000 QUIET, ALUMINUM (not shown)
19 21.9678.0767 1 EA ASSY, STABILIZER
19a - 10.9678.0757 1 EA STABILIZER, 1.377DIA
19b - 10.9678.0762 1 EA BRACKET, STABLIZER
19c - 53.6610.0003 1 EA SCREW, 6-32 X 7/16" PPZ
19d - 55.6568.0075 1 EA SPRING, EXTSN 0.375" OD 1.00" LG 0.041" WIRE DIA
20 21.9678.0805 1 EA ASSY, PANEL
21 21.9678.0807 1 EA ASSY, PAN PULLEY
