Vari Lite VL3000 - VL3000 and VL3000 Q Spot Luminaire

TOP ASSEMBLY : VL3000 AND VL3000Q SPOT LUMINAIRE
02.9678.0010 F 69
3
VL3000 and VL3000Q Spot Luminaire
20.9678.0001 Rev P
20.9678.0003 Rev E
Refer to Figure 3-11
No. Item Qty. UM. Description
- 02.8405.0001 1 EA AC DANGER TAG, VL3000 (not shown)
- 04.9661.0033.01 1 EA LABEL, WARNING - 2000 SERIES (not shown)
- 04.9661.0039 1 EA LABEL, LINE CORD WARNING (not shown)
- 04.9678.0041.01 1 EA LABEL, AC INPUT RATING VL3000 (not shown)
- 04.9678.0061 1 EA LABEL, AC INPUT RATING VL3000Q (not shown)
- 10.9678.0609 1 EA FRONT FILTER, FOAM, ZOOM (not shown)
1 10.9661.0617 1 EA YOKE CROSSMEMBER, HEAT SHIELD
2 10.9686.0732 2 EA COVER, YOKE THERMOFORM
3 10.9678.0670 1 EA INTERCONNECT PCB MOUNT, CYM
4 10.9678.0671 1 EA INTERCONNECT PCB MOUNT, RG
5 10.9678.0658 10 EA PLATE, COUNTERWEIGHT
6 21.9678.0010.01 1 EA ASSY, GENERIC LUMINAIRE
7 21.9678.0200 1 EA ASSY, SPOT GOBO
8 21.9678.8640.01 1 EA ASSY, HOT BOX, SPOT
21.9678.8698.01 1 EA ASSY, HOT BOX, QUIET SPOT
9 21.9678.0660.01 1 EA ASSY, FAN, TRAY DUCT
21.9678.0659.01 1 EA ASSY, FAN TRAY DUCT, QUIET SPOT
10 21.9678.0678.01 1 EA ASSY, TRANSFER FAN
11 21.9678.8611 2 EA ASSY, HEAD COVER
12 22.9678.0103 1 EA ASSY, SPOT OPTIC
13 22.9678.0402 1 EA ASSY, CLR/DIM/STROB
22.9678.0462 1 EA ASSY, CLR/DIM/STROB, QUIET SPOT
14 22.9678.0149 4 EA ASSY, ROD CLAMP
15 22.9678.0693 2 EA ASSY, GOBO CLAMP
16 22.9678.0694 2 EA ASSY, COLOR CLAMP
17 22.9678.1126 1 EA ASSY, LEAD SCREW EDGE
18 24.9678.3730 1 EA PCB ASSY, VL3000 CONTROLLER
- 25.9678.0675 1 EA CABLE ASSY, RELAY TO GOBO INTERLOCK SWITCH (not shown)
- 25.9678.0689 1 EA CABLE ASSY, YOKE TO HEAD GND (not shown)
- 25.9678.0677 1 EA CABLE ASSY, FRONT HEAD FANS (not shown)
