HEAD ASSEMBLY : YELLOW WHEEL ASSEMBLY
02.9678.0010 F 129
3
Yellow Wheel Assembly
22.9678.0474 Rev B
Refer to Figure 3-40
Figure 3-40: Yellow Wheel Assembly
No. Item Qty. UM. Description
1 22.9678.0420 1 EA PULLEY ASSY, WITH BEARING
2 41.9678.0473 1 EA GLASS, YELLOW COLOR WHEEL
1
2
Painted Timing Mark
Dichroic Coated Side
(Dichroic Coated Side Only)
To Next Page
