VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
58 02.9678.0010 F
Drawing Trees
VL3000 Spot Luminaire
Figure 3-1: VL3000 Spot Luminaire Subassembly Drawing Tree Part 1
VL3000 Spot Luminaire
20.9678.0001 Rev P
Motor/Adapter Plate
Assembly
21.9678.0331 Rev 0
continued next page
Transfer Fan Assembly
21.9678.0678.01 Rev C
Head Cover Assembly
21.9678.8611 Rev 0
Dual Fan Tray/Duct
Assembly
21.9678.0660.01 Rev B
Rod Clamp Assembly
22.9678.0149 Rev B
Edge Lead Screw
Assembly
22.9678.1126 Rev B
Gobo Clamp Assembly
22.9678.0693 Rev A
Color Clamp Assembly
22.9678.0694 Rev A
VL3000 Controller PCB
24.9678.3730 Rev 0
Generic Luminaire
Assemblies
21.9678.0010.01 Rev G
Spot Gobo Assembly
21.9678.0200 Rev H
(Spot Only)
Hot Box Assembly
21.9678.8640.01 Rev D
(Spot)
Color/Dimmer/Strobe
Assembly
22.9678.0402 Rev M
Backcap Interlok to Gobo
Fan Interlok Cable
Assembly
25.9678.0014 Rev B
Relay to Gobo Fan
Interlock Cable Assembly
25.9678.0675 Rev B
Yoke Assembly
21.9678.0700 Rev J
Upper Enclosure Assembly
21.9678.0800.01 Rev NN
Tilt Motor Assembly
21.9678.0765 Rev E
Relay Electrical
Assembly
23.9650.3327 Rev B
Solid State Ignitor PCB
24.9661.3126 Rev 0
Yoke Fan and Relay
Cable Assembly
25.9678.0681 Rev C
Yoke Fan Cable
Assembly
25.9678.0758 Rev A
Fixed Color Wheel
Assembly
21.9678.0334 Rev D
Dimmer Wheel
Assembly
22.9678.0435 Rev D
Strobe Assembly
22.9678.0403 Rev F
Cyan Wheel Assembly
22.9678.0472 Rev C
Yellow Wheel Assembly
22.9678.0474 Rev B
Magenta Wheel
Assembly
22.9678.0476 Rev B
CTO Wheel Assembly
22.9678.0478 Rev B
Color Sensor PCB #1
Mount Assembly
22.9678.0481 Rev B
Color Sense PCB #2
Mount Assembly
22.9678.0489 Rev B
Wheel Position Sensor
PCB Assembly
24.9678.3240 Rev 0
Rotating Gobo Wheel
Assembly
21.9678.0210 Rev B
Head Structure
Assembly
21.9678.0600 Rev C
Backend Assembly
21.9678.0615 Rev S
Rotating Effects Wheel
Assembly
21.9678.0211 Rev B
Iris Assembly
21.9678.0270 Rev A
Index Sensor PCB
Assembly
24.9663.3231 Rev 0
Air Duct OT Switch
Cable Assembly
25.9678.0690 Rev 0
OT Switch to Interlok
Cable Assembly
25.9678.0682 Rev C
Wheel Position Sensor
PCB Assembly
24.9678.3240 Rev 0
Spot Optic Assembly
22.9678.0103 Rev R (Spot
Only)
continued next page
