DRAWING TREES : VL3000 SPOT LUMINAIRE
02.9678.0010 F 59
3
VL3000 Spot Luminaire (continued)
Figure 3-2: VL3000 Spot Luminaire Subassembly Drawing Tree Part 2
Upper Enclosure Assembly
21.9678.0800.01 Rev NN
Spot Optic Assembly
22.9678.0103 Rev R (Spot Only)
Zoom Box Assembly
21.9678.0110 Rev F
Group 1 Lens Assembly
22.9678.1181 Rev A
Group 2 Lens Assembly
22.9678.0182 Rev A
Group 3 Lens Assembly
22.9678.0183 Rev 0
Group 4 Lens Assembly
22.9678.0199 Rev 0
Right Edge Bearing
Assembly
22.9678.1103 Rev C
Left Edge Bearing Assembly
22.9678.1105 Rev C
Zoom Cam Assembly
22.9678.1106 Rev B
Zoom Motor Tensioning
Assembly
22.9678.1113 Rev B
Interconnect Light Shield
Assembly
22.9678.1115 Rev D
Zoom Sensor (Target) PCB
Assembly
24.9678.3112 Rev 0
DMX Input PCB
24.9663.3830 Rev B
Display PCB
24.9678.3825 Rev A
Pan Pulley Assembly
21.9678.0807 Rev E
Pan Motor Assembly
21.9678.0864 Rev E
Pan Tube Assembly
21.9678.0881 Rev 0
Panel Assembly
21.9678.0805 Rev L
Upper Enclosure Fan
Assembly
23.9678.0686
EMI Filter to Power Switch
Cable Assembly
25.9678.0811 Rev C
AC Input Splitter Cable
Assembly
25.9678.0812 Rev E
Data I/O Link Cable
Assembly
25.9678.0813 Rev A
Display Cable Assembly
25.9678.1825 Rev E
Ballast to Controller Cable
Assembly
25.9678.0816 Rev A
DC Output Cable Assembly
25.9678.0821 Rev E
Pan/Tilt Control Cable
Assembly
25.9678.0818 Rev B
LVS to Yoke AC Fan Cable
Assembly
25.9678.0843 Rev A
continued from previous page
continued from previous page
Chassis To Yoke Ground
Cable Assembly
25.9661.1520 Rev C
LVS Chassis Ground Cable
Assembly
25.9661.1514 Rev A
Lamp Supply to Relay Cable
Assembly
25.9678.0829 Rev A
