Vari Lite VL3000 - Fixed Color Wheel Assembly

VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
120 02.9678.0010 F
Fixed Color Wheel Assembly
21.9678.0334 Rev D
Refer to Figure 3-32
No. Item Qty. UM. Description
1 10.9678.0322 1 EA SPIN SHAFT, COLOR WHEEL
2 10.9678.0332 6 EA SLIDING RETAINER
3 10.9678.0333 6 EA RETAINER CLIP
4 22.9678.1336 1 EA FAB ASSY, FIXED WHEEL/CLIP (changed 9-03-03)
5 41.9678.0305.01 1 EA COLOR FILTER, DEEP RED VL3000
6 41.9678.0305.02 1 EA COLOR FILTER, KELLY GREEN VL3000
7 41.9678.0305.03 1 EA COLOR FILTER, CONGO BLUE VL3000
8 41.9678.0305.04 1 EA COLOR FILTER, MAGENTA VL3000
9 41.9678.0305.05 1 EA COLOR FILTER, ORANGE VL3000
10 41.9678.0305.06 1 EA COLOR FILTER, DARK FUSHIA VL3000
11 53.6534.0001 6 EA RIVET, 3/32"OD POP 3/32 GRIP RANGE
12 53.6608.1857 3 EA SCREW, 6-32 X 3/16"LG PFSS
13 55.2256.0001 1 EA MAGNET, 2:17 SMCO 2MM X 2MM X 3MM
14 55.6568.0076 6 EA SPRING, CPRSN 0.120"OD 0.750"LG
15 10.9678.0250 1 EA MAGNET TAPE
