VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
72 02.9678.0010 F
VL3000 and VL3000Q Wash Luminaire
20.9678.0002 Rev M
20.9678.0004 Rev F
Refer to Figure 3-12
No. Item Qty. UM. Description
- 02.8405.0001 1 EA AC DANGER TAG, VL3000 (not shown)
- 04.9661.0033.01 1 EA LABEL, WARNING - 2000 SERIES (not shown)
- 04.9661.0039 1 EA LABEL, LINE CORD WARNING (not shown)
- 04.9678.0041.01 1 EA LABEL, AC INPUT RATING VL3000 (not shown)
- 04.9678.0061 1 EA LABEL, AC INPUT RATING VL3000Q (not shown)
1 10.9661.0617 1 EA YOKE CROSSMEMBER, HEAT SHIELD
2 10.9678.0670 1 EA INTERCONNECT PCB MOUNT, CYM
3 10.9678.0732 2 EA COVER, YOKE THERMOFORM
4 21.9678.0010.01 1 EA ASSY, GENERIC LUMINAIRE (changed 05-24-04)
5 21.9678.0611 2 EA ASSY, HEAD COVER
21.9678.8611 2 EA ASSY, HEAD COVER, VL3000Q WASH
6 21.9678.8640.02 1EAASSY, WASH HOT BOX
21.9678.8698.02 1 EA ASSY, HOT BOX, VL3000Q WASH
7 21.9678.0660.01 1 EA ASSY, FAN, TRAY/DUCT (changed 03-01-05)
21.9678.0659.01 1 EA ASSY, FAN, TRAY/DUCT, VL3000Q WASH
8 21.9678.0678.02 1 EA ASSY, TRANSFER FAN (changed 11-11-03)
9 21.9678.0910 1 EA ASSY, BEAM SPREADER
10 21.9678.0991 2 EA ASSY, LIGHT BAFFLE BEAM SPREAD
11 21.9678.0950 1 EA ASSY, APERATURE BULKHEAD
12 22.9678.0149 2 EA ASSY, ROD CLAMP
13 22.9678.0402 1 EA ASSY, CLR/DIM/STROB
22.9678.0462 1 EA ASSY, CLR/DIM/STROB, VL3000Q WASH
14 22.9678.0693 2 EA ASSY, GOBO CLAMP
15 22.9678.0694 2 EA ASSY, COLOR CLAMP
16 24.9678.3730 1 EA PCB ASSY, VL3000 CONTROLLER
- 25.9678.0675 1 EA CABLE ASSY, RELAY TO GOBO FAN (not shown)
- 25.9678.0677 1 EA CABLE ASSY, FRONT HEAD FANS (not shown)
- 25.9678.0689 1 EA CABLE ASSY, YOKE TO HEAD GND (not shown)
- 25.9678.0715 1 EA CABLE ASSY, HEAD CONTROL (not shown)
- 28.9678.0002 1 EA INCLUDED ITEMS KIT, VL3000 WASH (not shown)
