VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
116 02.9678.0010 F
Color/Dimmer/Strobe Assembly
22.9678.0402 Rev M
22.9678.0462 Rev D (VL3000Q)
Refer to Figure 3-30
No. Item Qty. UM. Description
1 10.9678.0324 1 EA PULLEY, FIXED COLOR WHEEL
2 10.9678.0337 1 EA DRIVE PULLEY, FIXED COLOR WHEEL (changed 03-09-06)
3 10.9678.0456 4 EA SHAFT, COLOR WHEEL
4 10.9678.0457.07 1 EA SPACER, COLOR WHEEL L.357 (changed 07-22-04)
5 10.9678.0457.02 2 EA SPACER, COLOR WHEEL L.190
6 10.9678.0457.03 3 EA SPACER, COLOR WHEEL L.123
7 10.9678.0457.04 3 EA SPACER, COLOR WHEEL L.031
8 10.9678.0469 1 EA REAR COLOR BULKHEAD
9 10.9678.0485 5 EA PULLEY, COLOR MOTOR
10 21.9678.0331 1 EA ASSY MOTOR/PLATE
11 21.9678.0334 1 EA ASSY, FIXED COLOR WHEEL
12 22.9678.0335 1 EA ASSY, BEARING BLOCK, FIXED WHEEL
- 10.9678.0323 1 EA WHEEL MOUNT
- 54.1259.0004 2 EA BEARING, RADIAL FLANGED 0.25"ID 0.625"OD (changed 6-25-03)
13 22.9678.0403 1 EA ASSY, STROBE
22.9678.0463 1 EA ASSY, STROBE (VL3000 QUIET)
14 22.9678.0435 1EAASSY, DIMMER WHEEL
15 22.9678.0472 1 EA ASSY, CYAN WHEEL
16 22.9678.0474 1EAASSY, YELLOW WHEEL
17 22.9678.0476 1 EA ASSY, MAGENTA WHEEL
18 22.9678.0478 1EAASSY, CTO WHEEL
19 22.9678.0481 1 EA MOUNT ASSY, COLOR SENSE PCB #1
20 10.9678.0486 1 EA FRONT COLOR BULKHEAD
21 22.9678.0489 1 EA ASSY, COLOR SENSE PCB #2 MOUNT
22 24.9678.3240 1 EA PCB ASSY, WHEEL POSITION SENSOR (changed 02-14-05)
- 25.9678.1409 1 EA PCB/CABLE ASSY, COLOR INTERCNT (not shown) (changed 06-28-06)
- 25.9678.1419 1 EA PCB/CABLE ASSY, COLOR INTERCNT (not shown) (VL3000 QUIET)
23 44.9678.0455 5 EA COLOR MOTOR
24 53.2202.0008 1 EA NUT, 8-32 HEX SS, NYLON INSERT
25 53.2200.0006 12 EA NUT, 6-32 KEPS SS
