Vari Lite VL3000 - Ballast to Controller Cable Assembly

CABLE ASSEMBLIES : BALLAST TO CONTROLLER CABLE ASSEMBLY
02.9678.0010 F 201
3
Ballast to Controller Cable Assembly
25.9678.0816 Rev A
Refer to Figure 3-100
Figure 3-100: Ballast to Controller Cable Assembly
No. Item Qty. UM. Description
1 52.6396.3002 1 EA RECEPT, 2 POS MTA100 W/POL TAB WHT CLSD END (changed 05-03-06)
2 52.6396.3005 1 EA RECEPT, 5 POS MTA100 W/POL TAB WHT CLSD END (changed 05-03-06)
3 52.6396.3008 1 EA RECEPT, 8 POS MTA100 W/POL TAB WHT CLSD END (changed 05-03-06)
4 73.5124.1289 3.67 FT WIRE, 24AWG 5COND <BLK-BRN-RED-GRN-WHT>
2
3
1
4
