ENCLOSURE ASSEMBLY : VENTILATION COVER ASSEMBLY - VL3000 QUIET

02.9678.0010 F 165

Ventilation Cover Assembly - VL3000 Quiet

21.9686.0840.02 Rev B

Refer to Figure 3-67

No. Item Qty. UM. Description

1 10.9686.1249 4 EA POST, TRUSS HOOK

1a 10.9678.0850 4 EA POST, TRUSS HOOK, SHORT, EARLY PRODUCTION

1b 10.9678.0833 4 EA SPACER, 1.25 "

2 10.9686.0883 1 EA COVER, VENTILATION

3 10.9678.0837 1 EA AIR SEAL, FAN SIDE

4 10.9678.0838 1 EA AIR SEAL, APS SIDE

5 10.9678.0835 1 EA AIR SEAL, SHORT STRIP

6 10.9678.0836 1 EA AIR SEAL, LONG STRIP

7 10.9678.0887 2 EA RAIN COVER SOUND INSULATION, ALUMINUM COVER

8 53.6653.0027 4 EA SCREW, 1/4-20 X 1 5/8 SOC HEAD

9 54.1206.0015 4 EA RING, RETAINING, PRESS-ON, 1" SH

10 55.6549.0001 4 EA WASHER, 1/4" SPLIT LOCK
