HEAD ASSEMBLY : SPOT OPTIC ASSEMBLY
02.9678.0010 F 101
3
Spot Optic Assembly
22.9678.0103 Rev R (Spot Only)
Refer to Figure 3-17 and Figure 3-18
No. Item Qty. UM. Description
1 10.9678.1131 1 EA FORWARD PULLEY SHAFT (changed 12-15-04)
2 10.9678.0127 1 EA PULLEY, IDLER
3 10.9678.0129 2 EA SPACER, ROLLER CAM
4 10.9678.0153 1 EA CABLE CLAMP, CAST
5 10.9678.0156 2 EA BARREL STRAP, G1 & G2
6 10.9678.0157 1 EA BARREL STRAP, G3
7 10.9678.0171 1 EA SHAFT, CAM PULLEY
8 10.9678.1185 1 EA LIGHT BAFFLE #2 (NOT SHOWN)
9 10.9678.1186 1 EA LIGHT BAFFLE #3
10 10.9678.1191 1 EA LIGHT BAFFLE, G3
11 12.9678.0174 1 EA LENS MOUNT, MACHINE G3
12 12.9678.1179.01 1 EA LENS MOUNT, MACHINE G1
13 12.9678.1179.02 1 EA LENS MOUNT, MACHINE G2
14 21.9678.0110 1 EA ASSY, ZOOM BOX
15 21.9678.0113 1 EA ASSY, RAIL & CARRIAGE
16 22.9678.1181 1 EA LENS ASSY, GROUP 1
17 22.9678.0182 1 EA LENS ASSY, GROUP 2
18 22.9678.0183 1 EA LENS ASSY, GROUP 3
19 22.9678.0199 1 EA ASSY, LENS MOUNT G4
20 22.9678.1103 1 EA ASSY, EDGE BEARING RIGHT
21 22.9678.1105 1 EA ASSY, EDGE BEARING LEFT
22 22.9678.1106 1 EA ZOOM CAM ASSY
23 22.9678.1113 1 EA ASSY, ZOOM MOTOR TENSIONING
24 22.9678.1115 1 EA INTERCONNECT, LIGHT SHIELD
25 22.9678.1190 1 EA LID ASSY, ZOOM BOX (changed 11-05-03)
- 12.9678.1189 1 EA LID, ZOOM BOX
- 53.2008.0006 1 EA NUT, PUSH #6
- 53.6522.0001 1 EA SCREW, 6-32 X 1/4" PPZ
- 55.3303.0006 1 EA WASHER, #6 LOCK INT. TOOTH SS
