VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
78 02.9678.0010 F
Head Cover Assembly
21.9678.0611 Rev K (VL3000 Quiet)
21.9678.8611 Rev 0
Refer to Figure 3-2
No. Item Qty. UM. Description
1 10.9678.0612 1 EA HEAD COVER FOAM BAFFLE
2 10.9678.0649 4 EA EJECTOR SPRING, BLACK OXIDE
3 10.9678.0674 1 EA BRACKET, COVER TETHER
4 10.9678.0696 1 EA FOAM FRAME, HEAD COVER (added 10-01-03)
5 12.9678.8610 1 EA HEAD COVER
12.9678.8610 1 EA HEAD COVER, PAINTED, VL3000 QUIET (changed 9-10-03)
6 53.5655.0250 4 EA SCREW, #6 X 1/4" PPZ PLASTIC
7 53.6558.0003 1 EA SCREW, 6-32 X 3/8"LG PPZ PLASTIC THD ROLL
8 55.2233.0016 4 EA RETAINER, SPLIT RING (changed 04-19-05)
9 55.2233.0775 4 EA STUD, 1/4 TURN OPR.775L STEEL BLK ZINC (changed 5-21-03)
10 55.9676.0255 4 EA WASHER, BEVELED SPRING (added 05-15-05)
