Vari Lite VL3000 - Spot Gobo Assembly

HEAD ASSEMBLY : SPOT GOBO ASSEMBLY
02.9678.0010 F 85
3
Spot Gobo Assembly
21.9678.0200 Rev H (Spot Only)
Refer to Figure 3-6
No. Item Qty. UM. Description
1 10.9678.0215 1 EA BULKHEAD, GOBO MODULE FRONT
2 10.9678.0216 1 EA BULKHEAD, GOBO MODULE REAR
3 10.9678.0225 4 EA SHAFT, GOBO WHEEL
4 10.9678.0231 3 EA PULLEY, MOTOR GOBO WHEEL DRIVE
5 10.9678.0232 3 EA PULLEY, INSEX DRIVE 64 GROOVE
6 10.9678.0244 2 EA MOUNT, INDEX SENSOR LONG
7 10.9678.0245 1 EA MOUNT, INDEX SENSOR SHORT
8 10.9678.0246 3 EA ADJUST PLATE, MOTOR
9 10.9678.0277 1 EA SPACER, WHEEL/IRIS
10 21.9678.0210 2 EA ASSY, ROTATING GOBO WHEEL
11 21.9678.0211 1 EA ASSY, ROTATING EFFECTS WHEEL
12 21.9678.0243 2 EA ASSY, MOTOR LONG SHAFT
13 21.9678.0270 1 EA SUB-ASSY, IRIS
14 24.9663.3231 4 EA PCB ASSY, INDEX SENSOR
15 24.9678.3240 3 EA PCB ASSY, WHEEL POSITION SENSOR (changed 02-11-05)
- 25.9678.2209 1 EA PCB/CABLE ASSY, GOBO INTERCONN (changed 06-28-06) (Not Shown)
16 44.9663.1202 2 EA MOTOR, 17 2.42" SHAFT 11.8MH
17 44.9663.1766 2 EA MOTOR, 17 1.24" SHAFT 11.8MH 5
18 53.5560.0187 12 EA SCREW, 8-32 X .187 " SET CONE (changed 06-21-05)
19 53.6520.0375 8 EA SCREW, 4-40 X 3/8" PPZ SEMS
20 53.6558.0009 4 EA SCREW, 6-32 X 3/8" PPZ SEMS
21 53.5638.0252 8 EA SCREW, 6-32 X 3/8" PFZ UNDERCUT HD
22 53.6613.0001 16 EA SCREW, 6-32 X 1/2" PPZ
23 54.2057.0001 3 EA BELT, TIMING MXL .080"PITCH 14
24 54.2058.0001 3 EA BELT, TIMING MXL .080"PITCH 16
25 55.2150.0002 4 EA STANDOFF, 1/4"HEX 6-32 1.187"L
26 55.2150.0003 4 EA STANDOFF, 1/4"HEX 6-32 1.125"L
27 55.2178.0001 4 EA CABLE ANCHOR MOUNT, #8 SCREW
28 53.6682.0002 6 EA SCREW, 4-40 X 1/4" PPZ SEMS
29 55.6506.0025 1 EA SPACER, 3/8"RND 1/8"LG .257" ID
30 55.6506.0026 1 EA SPACER, 3/8"RND 31/32"LG .257" ID
