Vari Lite VL3000 - Hot Box Assembly

VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
92 02.9678.0010 F
Hot Box Assembly
21.9678.8640.01 Rev D (Spot)
21.9678.8640.02 Rev D (Wash)
21.9678.8698.01 Rev C (Quiet Spot)
21.9678.8698.02 Rev C (Quiet Wash)
Refer to Figure 3-11
No. Item Qty. UM. Description
1 04.9678.0042 1 EA LABEL, VL3000 BACKCAP
10.9678.0043 1 EA LABEL, BACKCAP, VL3000 QUIET
2 10.9678.0641 1 EA HOT BOX
3 10.9678.0642 1 EA BACKCAP PLATE
4 10.9678.0643 1 EA LAMP ADJUST STOP
5 10.9678.0645 3 EA KNOB, LAMP ADJ MOLDED
6 10.9678.0646 1 EA TILT PLATE, XYZ ADJUSTMENT
7 10.9678.1648 4 EA GASKET, PRIMARY REFLECTOR
8 10.9678.2647 4 EA CLAMP, PRIMARY REFLECTOR
9 55.6759.0003 4 EA STANDOFF, PEM 6-32 X .562 LG, SST
10 55.6568.0077 4 EA SPRING, COMPRESSION, 0.035 " WIRE, 0.300 DIA X .625" LG
11 12.9678.7155 1 EA REFLECTOR, PRIMARY SMOOTH (Wash Only)
12.9678.7151 1 EA REFLECTOR, PRI 40 LUNE DUAL CURVATURE (Spot Only)
- 25.9661.1522 1 EA CABLE ASSY, HEAD TO BACKCAP GROUND (Not Shown)
- 25.9678.0789 1 EA CABLE ASSY, IGNITOR TO LAMP SOCKET (Not Shown)
12 53.6582.0001 4 EA SCREW, 6-32 X 3/4" PFZ
13 53.2030.0001 3 EA NUT, ACORN 10-32THD 3/8 WIDE, 3/16 THD DP BLK ZINC
14 53.5508.0375 2 EA SCREW, 8-32 X 3/8" PPSS
15 53.6530.0013 8 EA RIVET, 1/8"OD .063" - .125"GL CSK HD ALUM
16 55.2233.0003 4 EA RETAINER, PUSH-ON TYPE
17 55.2233.0006 4 EA STUD, 1/4 TURN OPR .455L STEEL
18 55.6546.0004 3 EA WASHER, TEFLON, .201ID X .438O
19 55.6568.0077 3 EA SPRING, CPRSN .300"OD .625"LG .035"WIRE DIA SS
20 71.2561.0002 1 EA LAMPHOLDER, SFC10-4 WITH PREFOCUS, SHARX (changed 12-06-06)
71.2571.0001 1 EA LAMPHOLDER, SFC10-4 WITH GOLD CONTACTS, SHARX (VL3000 Q)
