Vari Lite VL3000 - Index Sensor PCB Assembly

HEAD/YOKE PCB ASSEMBLIES : INDEX SENSOR PCB ASSEMBLY
02.9678.0010 F 157
3
Index Sensor PCB Assembly
24.9663.3231 Rev 0
Refer to Figure 3-64
Figure 3-64: Index Sensor PCB Assembly
No. Item Qty. UM. Description Ref.
1
11.9663.1231 1
EA
PCB, INDEX SENSOR
-
2
52.6447.0009 1
EA
HEADER, SHROUDED 4 POSITION
J1
3
86.7002.0005 1
EA
SWITCH, SLOTTED OPTICAL OPB6
S1
24-9663-
REV B VARI-LITE SENSOR INDEX
SOLDER SIDE VIEWED FROM SENSOR SIDE
1231
1
3
2
