Vari Lite VL3000 - AC Input Splitter Cable Assembly

CABLE ASSEMBLIES : AC INPUT SPLITTER CABLE ASSEMBLY
02.9678.0010 F 197
3
AC Input Splitter Cable Assembly
25.9678.0812 Rev E
Refer to Figure 3-97
No. Item Qty. UM. Description
1 52.6231.0001 1 EA PLUG HOUSING, MNLOK PLUG 3POS
2 52.8231.0005 1 EA TERM, RING #6 BLUE 16-14 AWG REEL PIDG
3 52.8231.0008 2 EA TERM, SPADE #6 RED 22-16AWG INSERT
4 52.8392.0001 2 EA RECP, FASTON 0.187"X0.32" 16-14 AWG FLAG DBL CRP
5 52.8270.0001 2 EA CONTACT PIN, 20-14AWG MNLOK (REEL)
6 52.8314.0001 1 EA PIN, GND 20-14AWG MNLOK .060"- .130"INS DIA
7 55.2186.0001 3 EA CABLE TIE, 0.10" WD 4.00" LG SMALL
8 55.6699.0003 1.50 FT SLEEVING, 1/2"NOM.DIA. POLY EXP BRAIDED
9 73.6016.0009 1.83 FT WIRE, 16AWG 600V 105C PVC WHT UL1015
10 73.6016.0010 1.83 FT WIRE, 16AWG 600V 105C PVC BLK UL1015
11 73.6016.0504 2.08 FT WIRE, 16AWG 600V 105C PVC GRN/YEL UL1015
12 73.6018.0009 1.00 FT WIRE, 18AWG 600V 105C PVC WHT UL1015
13 73.6018.0010 1.00 FT WIRE, 18AWG 600V 105C PVC BLK UL1015
