CABLE ASSEMBLIES : RELAY TO GOBO FAN INTERLOCK CABLE ASSEMBLY
02.9678.0010 F 183
3
Relay to Gobo Fan Interlock Cable Assembly
25.9678.0675 Rev B
Refer to Figure 3-84.
Figure 3-84: Relay to Gobo Fan Interlock Cable Assembly
No. Item Qty. UM. Description
1 52.8230.0003 1 EA RECEPT, 1/4" FASTON 22-18AWG (TAPE MOUNT)
2 52.8414.0001 1 EA RECEPT, FASTON 0.187 SERIES 24-20 AWG UNINSUL
3 73.7089.0000 2.00 FT WIRE. 22AWG 300V 200C TEF BLK UL1180
