yoke assemblies.
Houses zoom lens
and edge mechanisms.
Optics Assembly
Head Cover
Yoke Arm Cover
Yoke Arm
Houses lamp and reflector.
Provides knobs for lamp
Backend Assembly
adjustment.
Main Controller Board (MCB)
Luminaire control circuit board.
Contains three rotating
gobo wheels and beam-
Gobo Assembly
size iris mechanism.
Contains lamp power
cut-off switch so that it
Fan Assembly
cannot be disengaged.
Contains fixed color wheel,
dimmer mechanism, strobe
Color Assembly
mechanism, CYM color mixer
Enclosure Assembly
see page 8
(attached by tether)
Head Cover
(attached by tether)
Cover
and CTO color correction.
To Next Page
