VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
94 02.9678.0010 F
Gobo/Color Fan Assembly - VL3000Q only
21.9678.0659.01 Rev D
Refer to Figure 3-13
No. Item Qty. UM. Description
1 10.9678.0665 1 EA SPRING, EXTENSION ELONGATED HO
2 22.9678.0661 1 EA ASSY, FAN TRAY
3 22.9678.0665 1 EA DUCT ASSY
4 23.9678.0699 2 EA FAN ASSY, HEAD FRONT
5 53.5506.1375 6 EA SCREW, 6-32 X 1 3/8"LG PPB
6 53.6519.0001 2 EA SCREW, 4-40 X 5/8" PPZ
7 53.6530.0006 2 EA RIVET, 1/8" OD POP .188-.250GL
8 55.2179.0003 2 EA SADDLE, CABLE, .75 X .75" 4-WAY ADH BACK WHT
9 55.2186.0001 2 EA CABLE TIE, .10"WD X 4" LG SMALL (not shown)
10 55.6538.0002 2 EA WASHER, #6 NYLON NATURAL
11 55.6818.0002 1 EA STANDOFF, 45 DEG NYLON 6/6 KUR
12 74.1099.0001 1 EA SWITCH, MINIATURE 5AMP 150DEG
