Vari Lite VL3000 - Chassis to Yoke Ground Cable Assembly

CABLE ASSEMBLIES : CHASSIS TO YOKE GROUND CABLE ASSEMBLY
02.9678.0010 F 177
3
Chassis To Yoke Ground Cable Assembly
25.9661.1520 Rev C
Refer to Figure 3-78
Figure 3-78: Chassis To Yoke Ground Cable Assembly
No. Item Qty. UM. Description
1 52.8250.0006 2 EA TERM, #8, RING, 10AWG
2 73.7089.0504 15.17
FT
WIRE, 22 AWG 300V 200C TEF GRN/YEL UL1180
1 (x2)
2 (7 x 26.0" LG)
