Vari Lite VL3000 - Zoom Sensor (Target) PCB Assembly

VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
156 02.9678.0010 F
Zoom Sensor (Target) PCB Assembly
24.9678.3112 Rev 0
Refer to Figure 3-63
Figure 3-63: Zoom Sensor PCB Assembly
Ref. Item Qty. UM. Description
- 11.9678.0112 1 EA PCB, VL3000 ZOOM SENSOR
J1 52.6447.0008 1 EA HEADER, SHROUDED 3 POSITION
S1 86.7002.0005 1 EA SWITCH, SLOTTED OPTICAL OPB610
c 2003
S1
6/16/03
