Vari Lite VL3000 - Head Controller Cable Assembly

VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
190 02.9678.0010 F
Head Controller Cable Assembly
25.9678.0715 Rev C
Refer to Figure 3-91
No. Item Qty. UM. Description
1 52.6224.1014 2 EA COVER, FRONT 14 POS MT LATCHING
2 52.6224.1040 2 EA COVER, FRONT 40 POS MT LATCHING
3 52.6224.1050 2 EA COVER, FRONT 50 POS MT LATCHING
4 52.6224.2014 2 EA COVER, BACK 14 POS MT
5 52.6224.2040 2 EA COVER, BACK 40 POS MT
6 52.6224.2050 2 EA COVER, BACK 50 POS MT
7 52.6610.0014 2 EA CONN, HOUSING, 14 POS 26-22 AWG DBL ROW UNLOADED (changed 05-
01-06)
8 52.6610.0017 2 EA CONN, HOUSING, 50 POS 26-22 AWG DBL ROW UNLOADED (changed 05-
01-06)
9 52.6610.0040 2 EA CONN, HOUSING, 40 POS 26-22 AWG DBL ROW UNLOADED (changed 05-
01-06)
10 52.8351.0004 180 EA CONTACT, 26-22 AWG RECP MTE (REEL) (added 05-01-06)
11 55.2186.0001 11 EA CABLE TIE, 0.10" WD 4.00" LG SMALL
12 55.6699.0004 1.75 FT SLEEVING, 3/4" NOM.DIA. POLY EXP BRAIDED
13 73.3026.0009 1.83 FT WIRE, 26 AWG 300V 80C <WHT>
14 73.5116.0123 35.17 FT WIRE, 24 AWG 4COND TW 300V 80C <BLK-BRN-RED-ORG> UL1061
15 73.5126.0002 6.00 FT WIRE, 26 AWG 2 COND TWISTED <RED-BLK>
16 73.5126.0007 1.83 FT WIRE, 26 AWG 2 COND 300V 80C UL1061 19 STRND <VIO-BLK>
17 73.5126.6009 2.33 FT WIRE, 26 AWG 6 COND TWISTED <WHT-WHT/BLU-WHT/BLK-WHT/
BRN-WHT/GRN-WHT/RED>
18 73.5126.7009 1.83 FT WIRE, 26 AWG 7 COND TWISTED <WHT-WHT/BLU-WHT/BLK-WHT/
BRN-WHT/GRN-WHT/RED-WHT/VIO>
