Vari Lite VL3000 - Page 211

CABLE ASSEMBLIES : HEAD CONTROLLER CABLE ASSEMBLY
02.9678.0010 F 191
3
Head Controller Cable Assembly (continued)
Figure 3-91: Head Controller Cable Assembly
11 (x11)
7, 1, 4
9, 2, 5
12
9, 2, 5
7, 1, 4
8, 3, 6
8, 3, 6
12
