Vari Lite VL3000 - Top Assembly; Included Items Kit, Spot

VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
66 02.9678.0010 F
Top Assembly
Included Items Kit, Spot
28.9678.0001 Rev H
Refer to Figure 3-9.
No. Item Qty. UM. Description
1 02.8001.0001 1 EA PRODUCT SUPPORT SHEET, VARI-LITE CUSTOMER SERVICE
2 02.8052.0001 1 EA CARD, LIMITED WARRANTY
3 02.8406.0001 1 EA TAG, LAMP NOTICE
4 02.8700.0001 1 EA CARD, PRODUCT REGISTRATION
5 02.9678.0002 1 EA UNPACK/QUICK START SHEET, VL3000
- 04.4037.0001 5 EA LABEL, 2.5 X .5 BARCODE (not shown)
- 07.9678.0036 1 EA CARDBOARD SHIPPING BOX, VL3000 (not shown)
6 08.3000.0001 1 EA CD-ROM, VL3000 PRODUCT DOCUMENTATION, USER
7 22.9661.1636 2 EA FAB ASSY, BRACKET TRUSS HOOK
8 41.6030.4211 1 EA GOBO ASSY, UNEVEN BARS (POS 2-4)
9 41.6030.5011 1 EA GOBO ASSY, NIGHT SKY (POS 1-3)
10 41.6030.5503 1 EA GOBO ASSY, PALM LEAVES (POS 2-2)
11 41.6030.5523 1 EA GOBO ASSY, TRIBAL BREAKUP (POS 1-4)
12 41.6030.6011 1 EA GOBO ASSY, CIRCLE OF OVALS (POS 3-5)
13 41.6030.7002 1 EA GOBO ASSY, PEBBLES (POS 1-5)
14 41.6030.7014 1 EA GOBO ASSY, TRIANGLE BREAKUP (POS 3-4)
15 41.6030.7018 1 EA GOBO ASSY, SHOCK BREAKUP (POS 2-3)
16 41.6030.7029 1 EA GOBO ASSY, ALPHA RAYS (POS 1-2)
17 41.6030.8003 1 EA GAG ASSY, 3-FACET PRISM (POS 3-2)
18 41.6030.8503 1 EA GAG ASSY, GLACIER (POS 1-6)
19 41.6030.8506 1 EA GAG ASSY, DROPLETS (POS 2-6)
20 41.6030.8509 1 EA GAG ASSY, ICE BLOCKS (POS 2-5)
21 41.6030.8801 1 EA GOBO ASSY, MULTI-COLOR CIRCLES (POS 3-3)
22 71.2557.1200 1 EA LAMP, 1200 WATT SHORT ARC, DOUBLE-ENDED
