Vari Lite VL3000 - Solid State Ignitor PCB

HEAD/YOKE PCB ASSEMBLIES : SOLID STATE IGNITOR PCB
02.9678.0010 F 149
3
Solid State Ignitor PCB
24.9661.3126 Rev 0
Refer to Figure 3-58
Ref. Item Qty. UM. Description
- 11.9661.1126 1 EA PCB, SOLID STATE IGNITOR
J1, J2, J3,
J4
52.8218.0003 4 EA TERM, PC, 6-32 SCREW
- 53.6690.0001 4 EA SCREW, 6-32 X 1/4" PPMS NICKELP
R11 60.1232.6493 1 EA RES, 1/4W 1% 6.49 K MF
R14 60.1443.1007 1 EA RES, 1/4W 5% 10.0 OHM
R1 60.1436.5104 1 EA RES, 1/4W 5% 51.0 K CF
R7 60.1437.1205 1 EA RES, 1/4W 5% 120.0 K CF
R15 60.1438.2001 1 EA RES, 1/4W 5% 2.0 K CF
R17 60.1439.1005 1 EA RES, 1/4W 5% 10.0 K CF
R10 60.1441.1003 1. EA RES, 1/4W 5% 100.0 K CF
R6 60.1445.5104 1 EA RES, W5% 51K OHM METAL OXIDE
R8, R9 60.1445.5600 2 EA RES, 1W 5% 5.6 OHM MET O
R3, R4 60.1445.8205 2 EA RES, 1W 5% 820K OHM METAL OXIDE
C6 62.3039.2101 1 EA CAP, 100PF 200V RAD CER 10% COG
C5 62.3039.2330 1 EA CAP, 330PF 200V RAD CER 5% COG
C8 62.3040.0104 2 EA CAP, 0.1UF 50V RAD CER 20% Z5U
C1 62.3041.0102 1 EA CAP, 1000PF 3KV 10% RAD CER DISC X7R
C2 62.3045.0106 1 EA CAP, 10UF 50V RAD ALUM 4 X 11 MM 20%
C4 62.3045.0475 1 EA CAP, 4.7UF 50V RAD ALUM 5 X 11 MM 20%
L1 68.9661.1126 1 EA COIL, IGNITOR SOLID STATE
D1 71.2564.0002 1 EA LIGHT, NEON STANDARD BRIGHTINESS
Q2 80.2623.0002 1 EA TRANSISTOR, 2N4401 NPN 40V 600
Q3 80.2623.0004 1 EA TRANSISTOR, 2N4403 PNP 40V 600
Q1 80.2657.0002 1 EA
TRANSISTOR, BIMOSFET IXBH16N17
D3 82.4333.4937 1 EA DIODE, 1N4937 FAST 600V 1A
D4, D5 82.4332.0002 2 EA DIODE, MUR8100E 1000V 8A
D2 82.5351.0002 1 EA DIODE, ZENER 20V 1W 5% DO-41
D6 82.5373.0002 1 EA DIODE, 1N5955B ZENER 180V 3W
U1 83.3212.0002 1 EA IC, MC14536B PROGRAMMABLE TIMER DIP 16
