Vari Lite VL3000 - Head Front Fan Assembly

HEAD ASSEMBLY : HEAD FRONT FAN ASSEMBLY
02.9678.0010 F 97
3
Head Front Fan Assembly
23.9678.0684 Rev 0
Refer to Figure 3-14
Figure 3-14: Head Front Fan Assembly
No. Item Qty. UM. Description
1 40.7125.0001 1 EA FAN, 24V FAL6F24LH
2 52.6523.0002 1 EA CONN, HOUSING 2POS PLUG SHROUDED WIRE TO WIRE
3 52.8347.0001 2 EA CONTACT, 24-30AWG MALE CRIMP
1
2
3 (x2)
