Vari Lite VL3000 - Arc Zoom Interconnect PCB Assembly

VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
154 02.9678.0010 F
Arc Zoom Interconnect PCB Assembly
24.9678.3116 Rev 0 (Spot Only)
Refer to Figure 3-62
Ref. Item Qty. UM. Description
- 04.9678.1116.00 1 EA LABEL SET ZOOM HARNESS (Not Shown)
- 11.9678.1116 1 EA PCB ZOOM INTERCONNECT
J3 52.6259.0008 1 EA HDR 4POS NT\MTA100 SD RT ANG
J4 52.6260.0015 1 EA HEADER, 2POS MTA-100 SHROUDED
J2 52.6447.0009 1 EA HEADER, SHROUDED 4 POSITION
52.6467.0009 1 EA CONN, FEM PLUG 3POS 30-24AWG
52.6467.0010 3 EA CONTACT, SOCKET 30-24AWG CRIMP
J1 52.6598.0029 1 EA HDR 14P 2ROW AMP MODU R/A
52.6662.0007 1 EA HOUSING, 6POS 125V/2A 2.00
52.8388.0003 4 EA CONTACT, 24-30AWG FEMALE CRI
55.2186.0001 1 EA CABLE TIE, 0.10" WD 4.00" LG SMALL
R1 60.1440.2703 1 EA RES, 1/4W 5% 270.0 OHM CF
73.2324.0030 0.54 FT WIRE, 24 AWG 3CD TW 300V 200C
73.2324.0124 0.46 FT WIRE, 24 AWG 4CD TW 300V 200C
