VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
134 02.9678.0010 F
Edge Lead Screw Assembly
22.9678.1126 Rev B
Refer to Figure 3-45
Figure 3-45: Edge Lead Screw Assembly
No. Item Qty. UM. Description
1 10.9678.1119 1 EA LEAD SCREW, EDGE
2 55..6616.0007 1 EA STANDOFF, 3/8" HEX THRD 0.562" LG
1
2
