HEAD ASSEMBLY : CTO WHEEL ASSEMBLY
02.9678.0010 F 131
3
CTO Wheel Assembly
22.9678.0478 Rev B
Refer to Figure 3-42
Figure 3-42: CTO Wheel Assembly
No. Item Qty. UM. Description
1 22.9678.0420 1 EA PULLEY ASSY, WITH BEARING
2 41.9678.0477 1 EA GLASS, COATED CTO
2
Painted Timing Mark
(Dichroic Coated Side Only)
Dichroic Coated Side
1
To Next Page
