Vari Lite VL3000 - Data I;O Link Cable Assembly

CABLE ASSEMBLIES : DATA I/O LINK CABLE ASSEMBLY
02.9678.0010 F 199
3
Data I/O Link Cable Assembly
25.9678.0813 Rev A
Refer to Figure 3-98
Figure 3-98: Data I/O Link Cable Assembly
No. Item Qty. UM. Description
1 52.6396.2904 1 EA RECEPT, 4 POS MTA100 W/POL TAB RED CLSD END (changed 05-03-06)
2 52.6396.2905 1 EA RECEPT, 5 POS MTA100 W/POL TAB RED CLSD END (changed 05-03-06)
3 73.5122.0259 2.17 FT CBL, 22AWG STRND 4COND PVC INSUL
2
1
3
