VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
102 02.9678.0010 F
26 23.9678.1120 1 EA LINEAR ACTUATOR ASSEMBLY
- 44.9678.0119 1 EA LINEAR ACTUATOR EDGE DRIVE
- 52.6467.0004 1 EA 4 POS 30-24 AWG CRIMP PHR
- 52.6467.0024 4 EA CONTACT, SOCKET 30-24AWG CRIMP (REEL) PH (JST)
27 24.9678.3112 1 EA PCB ASSY, VL3000 ZOOM SENSOR
28 53.2004.0002 1 EA NUT, 8-32 KEPS ZINC PLATE
29 53.2213.0001 7 EA NUT, #6 KEPS (changed 03-24-04)
30 53.5564.0250 2 EA SCREW, 6-32 X 1/4" PFB UNDERCUT (added 04-07-06)
31 53.5604.0375 5 EA SCREW, 4-40 X 3/8" PPB (changed 03-24-04)
32 53.6513.0023 6 EA SCREW, M3 X 8MM LG PFZ METR
33 53.6558.0009 17 EA SCREW, 6-32 X 3/8" SEMS (changed 03-24-04)
34 53.6558.0016 1 EA SCREW, 6-32 X 3/4" LG PPS SEMS (changed 3-03-04)
35 53.6596.0002 4 EA SCREW, 4-40 X 5/16" LG PPZ SEMS (changed 3-03-04)
36 53.6609.0001 6 EA SCREW, 6-32 X 3/8" PFZ
37 53.6613.0008 4 EA SCREW, 6-32 X 1/2" LG PPZ SEMS (added 3-03-04)
38 53.6614.0003 2 EA SCREW, 6-32 X 5/8" PFZ (
NOT SHOWN)
39 53.6617.0003 1 EA SCREW, 6-32 X 1" PPB SEMS (changed 3-03-04)
40 53.6682.0025 2 EA SCREW, 8-32 X 5/8" LNG PPZ SEMS (changed 11-19-03)
41 54.1261.0001 6 EA BUSHING, LOW DAMP THERMOPLASTIC .189" ID .5" OD
42 55.2234.0001 1 EA RING, RETAINING E-STYLE GRV.188 DIA (changed 02-06-05)
43 54.2053.0001 1 EA MXT T BELT PULLEY, 20GRV .25WD
44 54.2054.0001 1 EA BELT, TIMING MXL .080 PITCH 235 G, 3/16" WIDE, POLYU/KEVLAR
45 54.1262.0001 2 EA BEARING, FLANGED EXTENDED .1875 BORE (changed 12-15-04)
46 55.2283.0001 4 EA SHIM, SPACER .253" IDX, .010" THK
47 55.6503.0004 3 EA WASHER, #8 FLAT ZINC (changed 03-24-04)
48 55.6528.0001 5 EA WASHER, #6 FLAT ZINC
49 55.6578.0073 1 EA SPRING, EXTSN .375"OD
50 55.6846.0001 2 EA CAM FOLLOWER, 3MM DIA STUD
51 10.9678.1140 1 EA SHOCK PAD, G1 (added 12-15-04)
52 10.9678.1141 1 EA BACKING PLATE, SHOCK PAD, G1 (added 12-15-04)
No. Item Qty. UM. Description
