Vari Lite VL3000 - Page 137

HEAD ASSEMBLY : COLOR/DIMMER/STROBE ASSEMBLY
02.9678.0010 F 117
3
26 53.5559.0250 12 EA SCREW, 6-32 X 1/4" SET CONE PO
27 53.5638.0252 12 EA SCREW, 6-32 X 1/4"LG PFS UNDERCUT HEAD
28 53.6558.0001 7 EA SCREW, 6-32 X 3/8" PPZ
29 53.6597.0001 2 EA SCREW, 4-40 X 3/16" PPZ
30 53.6608.0003 5 EA SCREW, 6-32 X 3/16"LG PPZ
31 54.2036.0017 1 EA BELT, TIMING N=150 W=.125 URETHANE/KEVLAR
32 54.2059.0001 4 EA TIMING BELT, MXL PITCH 150 TOOTH SI/KEVLAR
33 54.2060.0001 1 EA BELT, TIMING MXL PITCH 165 TOOTH SI/KEVLAR
34 55.2132.0011 4 EA STANDOFF, 1/4"HEX 6-32 X 1.093"L SS
35 55.2132.0012 4 EA STANDOFF, 1/4"HEX 6-32 X 0.75"LG SS
36 55.3303.0004 2 EA WASHER, #4 LOCK INT.TOOTH SS
37 55.3303.0006 6 EA WASHER, #6 LOCK INT.TOOTH SS
38 55.6503.0004 1 EA WASHER, #8 FLAT ZINC
39 55.6528.0001 2 EA WASHER, #6 FLAT ZINC
40 55.2110.0002 2 EA SPACER, 0.010 LG
- 55.2186.0002 5 EA CABLE TIE, 0.09WD, 0.375 LG, TEFZEL (not shown)
41 10.9678.0457.06 1 EA SPACER, COLOR WHEEL, 0.015 L
42 55.6520.0001 2 EA WASHER, WAVE SPRING, 1/4" DIA (added 05-17-04) (VL3000 only)
No. Item Qty. UM. Description
