TOP ASSEMBLY : VL3000 AND VL3000Q WASH LUMINAIRE
02.9678.0010 F 73
3
17 53.6543.0001 8 EA SCREW, 6-32 X 3/8" PPB
18 53.6558.0009 11 EA SCREW, 6-32 X 3/8" LG PPZ SEMS
19 53.6558.0016 2 EA SCREW, 6-32 X 3/4" PPZ SEMS
20 53.6579.0001 4 EA SCREW, 10-32 X 1/2" SCB
21 53.6613.0001 2 EA SCREW, 6-32 X 1/2" PPZ
22 53.6682.0022 8 EA SCREW, 8-32 X 3/8" LG PPZ SEMS
23 55.2178.0001 1 EA CABLE ANCHOR MOUNT, #8 SCREW MOUNT
24 55.2284.0001 1 EA CARD GUIDE, 3" LONG SNAP IN
25 55.6506.0024 2 EA SPACER, 3/16" RND .1875" LG .141" THRU SS
26 55.6528.0001 2 EA WASHER, #6 FLAT ZINC
27 55.2150.0002 2 EA STANDOFF, 1/4 " HEX 6-32 1.188" LG MF STL (changed 5-27-03)
28 55.6677.0033 4 EA WASHER, .281" OD .125" ID .032" THK FLAT SS
29 53.6558.0007 2 EA SCREW, 6-32 X 1/4"LG PPZ SEMS EXT ZINC PLT (added 7-07-03)
- 55.6699.0003 .83 FT SLEEVING, 1/2"NOM.DIA. POLY (not shown)
- 55.6699.0004 1.16 FT SLEEVING, 3/4"NOM.DIA. POLY (not shown)
No. Item Qty. UM. Description
