VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
70 02.9678.0010 F
- 25.9678.0715 1 EA CABLE ASSY, HEAD CONTROLLER (not shown)
- 28.9678.0001 1 EA INCLUDED ITEMS KIT, VL3000 SPOT (not shown)
19 53.2001.0003 4 EA NUT, 10-32 NYLON INSERT
20 53.2002.0003 4 EA NUT, 6-32 HEX ZINC NYLON IN
21 53.6543.0001 8 EA SCREW, 6-32 X 3/8" PPB
22 53.6558.0009 8 EA
SCREW, 6-32 X 3/8"LG PPZ SEMS
® *
23 53.6616.0001 4 EA SCREW, 6-32 X 3/4" PPZ SEMS
24 53.6579.0001 4 EA SCREW, 10-32 X 1/2" SCB
25 53.6613.0001 2 EA SCREW, 6-32 X 1/2" PPZ
26 53.6614.0003 4 EA SCREW, 6-32 X 5/8" PFZ
27 55.2284.0001 2 EA CARD GUIDE, 3" LONG SNAP IN
28 55.6506.0024 2 EA SPACER, 3/16"RND .1875"LG .141 THRU SS
29 55.6528.0001 2 EA WASHER, #6 FLAT ZINC
30 55.6573.0001 2 EA HARDENED SHAFT, 10MM DIA X 200MM HARDENED
31 55.6616.0001 4 EA STANDOFF, 3/8 "HEX 6-32 THRD
32 55.2150.0002 2 EA STANDOFF, 1/4 " HEX 6-32 1.188"LG MF STL (changed 05-27-03)
33 55.6677.0033 4 EA WASHER, .201" OD .125" ID .032" THK FLAT SS
34 53.6558.0007 4 EA SCREW, 6-32 X 1/4"LG PPZ SEMS EXT ZINC PLT (added 07-07-03)
- 55.6699.0003 .830 FT SLEEVING, 1/2"NOM.DIA. POLY (not shown)
- 55.6699.0004 1.16 FT SLEEVING, 3/4"NOM.DIA. POLY (not shown)
35 53.2202.0008 1 EA NUT, 8-32 HEX SS NYLON INSERT (added 05-24-04)
No. Item Qty. UM. Description
* SEMS
®
is a registered tradmakrk of Illinois Tool Works (ITW)
