VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
160 02.9678.0010 F
22 21.9678.0864 1 EA ASSY, PAN MOTOR
23 21.9678.0881 1 EA ASSY, PAN TUBE
24 22.9678.0851 1 EA ASSY, UPPER ENCLOSURE
25 23.9678.0686 1 EA FAN ASSY, UPPER ENCLOSURE
23.9678.0888 1 EA FAN ASSY, UPPER ENCLOSURE, SLOW, VL3000 QUIET
26 23.9678.0687 1 EA ELEC ASSY, PAN EOT SENSOR
- 25.9661.1514 1 EA CABLE ASSY, LVS CHASSIS GND (not shown)
- 25.9661.1520 1 EA CABLE ASSY, CHASSIS TO YOKE GND (not shown)
- 25.9678.0811 1 EA CABLE ASSY, EMI FILTER TO POWER (not shown)
- 25.9678.0812 1 EA CABLE ASSY, AC INPUT SPLITTER (not shown)
- 25.9678.0813 1 EA CABLE ASSY, DATA I/O LINK (not shown)
- 25.9678.0816 1 EA CABLE ASSY, BALLAST TO CONTROL (not shown)
- 25.9678.0818 1 EA CABLE ASSY, PAN/TILT CONTROL (not shown)
- 25.9678.0821 1 EA CABLE ASSY, DC OUTPUT (not shown)
- 25.9678.1825 1 EA CABLE ASSY, DISPLAY (not shown)
- 25.9678.0829 1 EA CABLE ASSY, LAMP SUPPLY TO RELAY (not shown)
- 25.9678.0843 1 EA CABLE ASSY, AC FAN LVS TO YOKE (not shown)
27 52.8295.0002 1 EA TERMINAL STRIP, 300V 12AWG 20A
28 53.2001.0003 1 EA NUT, 10-32 NYLON INSERT
29 53.2019.0004 4 EA NUT, 3/8-16 X 7/32" THK HEX
30 53.2200.0006 4 EA NUT, 6-32 KEPS SS
31 53.6505.0022 3 EA BOLT, 3/8-16 X 3/4"LG CARR
32 53.6513.0044 3 EA SCREW, M5 X 10MM STL CUP PT
33 53.6515.0001 4 EA SCREW, 10-32 X 3/4" SCB CAP
34 53.6522.0001 1 EA SCREW, 6-32 X 1/4" PPZ
35 53.6522.0004 2 EA SCREW, 6-32 X 1/4" SOC HD
36 53.6525.0188 2 EA SCREW, 6-32 X 3/16" PPZ SEMS
37 53.6530.0023 2 EA RIVET, 1/8"OD POP .376-.500GRP
38 53.6539.0001 4 EA WASHER, 3/8" SPLIT LOCK
39 53.6545.0003 4 EA SCREW, 8-32 X 3/8" PFZ
40 53.6545.0004 4 EA SCREW, 8-32 X 3/8" PPZ
41 53.6556.0002 1 EA SCREW, 4-40 X 3/4"LG
42 53.6558.0009 13 EA SCREW, 6-32 X 3/8"LG PPZ SEMS
43 53.6558.0010 11 EA SCREW, 6-32 X 1/4"LG PPZ BLACK
44 53.6558.0015 4 EA SCREW, 6-32 X 3/8" PPB SEMS EXT
45 53.6571.0003 1 EA SCREW, 6-32 X 1-1/2"LG PPB
46 53.6591.0001 2 EA SCREW, 6-32 X 1/4" PFZ
47 53.6609.0001 4 EA SCREW, 6-32 X 3/8" PFZ
No. Item Qty. UM. Description
