ENCLOSURE ASSEMBLY : UPPER ENCLOSURE ASSEMBLY
02.9678.0010 F 161
3
48 53.6626.0001 1 EA SCREW, 10-32 X 1/2" PPZ
49 53.6634.1000 1 EA SCREW, 3/8-16 X 1.00" LG SOC
50 53.6653.0502 4 EA SCREW, 1/4-20 X 1/2"LG SOC (NOT USED ON VL3000Q)
51 54.1206.0014 2 EA RING, RETAINING
52 54.1255.0001 1 EA BEARING ASSY, BLACK FLUSH MOU
53 54.2055.0001 1 EA BELT, TIMING S2M 210GROOVE 9MM
54 55.2150.0003 2 EA STANDOFF, 1/4"HEX 6-32 1.125"L
55 55.2178.0001 2 EA CABLE ANCHOR MOUNT, #8 SCREW
56 55.2179.0001 3 EA CABLE ANCHOR MOUNT, #6 SCREW
57 55.2186.0001 5 EA CABLE TIE, .10"WD 4.00"LG SMALL
58 55.2261.0001 1 EA SLEEVE, NYLON THIN WALL #6 SCR
59 55.2267.0001 2 FT RUBBER STRIP, SPONGE CLSD CELL
60 55.6677.0039 4 EA WASHER, 0.438" OD X 0.219" ID X 0.040" THK
61 55.6532.0004 2 EA BRACKET, 6-32 THREADED HOLES
62 55.6543.0001 0.312 FT GROMMET STRIP, SERRATED .062"
63 55.6543.0002 1.54 FT GROMMET STRIP, SERRATED .125"
64 55.6549.0001 4 EA WASHER, 1/4" SPLIT LOCK (
NOT USED ON VL3000Q)
65 55.6568.0074 2 EA SPRING, CPRSN .420"OD .750"LG 0.055" DIA WIRE
66 55.6575.0001 4 EA SCREW, 10-32 X 3/4" PPB
67 55.6577.0005 2 EA STANDOFF, 1/2" HEX 6-32 X 1.625" L
68 55.6580.0002 2 EA CABLE TIE, 0.18" WD 8.0" LG
69 55.2132.0012 1 EA STANDOFF, 1/4" HEX 6-32 X 3/4" LG
70 55.6677.0044 1 EA WASHER, .877"OD.170"ID.093"THK
71 55.6699.0010 0.50 FT SLEEVING, 5/16" NOM DIA WOVEN POLY ROUNDIT
72 55.6775.0009 1 EA BUSHING, SNAP .750"ID 1"MT H
73 67.4018.0001 1 EA FERRITE, 26 X 28.5 X 13MM CYL
74 67.4021.0002 1 EA FILTER, EMI, CCI
75 68.9678.0827 1 EA CHOKE, COMMON MODE
76 69.3177.0151 1 EA POWER SUPPLY, 150W +24V/6.3A WMTH PLT (LAMBDA)
77 55.6799.0001 A/R EA PAN TUBE BEARING SHIM, 1.375" ID 1.875" OD, 0.005" THK (not shown)
78 55.6799.0002 A/R EA PAN TUBE BEARING SHIM, 1.375" ID 1.875" OD, 0.010" THK (not shown)
No. Item Qty. UM. Description
To Next Page
