VARI❋LITE® - VL3000™ SERIES LUMINAIRE SERVICE MANUAL
22 02.9678.0010 F
Figure 2-4: Gobo Replacement
Press from this side
Front of luminaire
Gobo Wheel
Gobo Assembly
Carrier
Top Head Cover *
Bottom Head Cover *
1/4-Turn Screw
Gobo Wheel
(see detail)
CAUTION:
Do not touch glass with bare fingers.
Press on gobo carrier only.
* Head covers are attached by tethers.
