MAINTENANCE PROCEDURES : TILT MOTOR ASSEMBLY AND TILT BELT REPLACEMENT
02.9678.0010 F 43
2
WARNING: Make sure wiring is not pinched during installation. When tightening four 10-32x1/2"
PPZ screws that mount Pan Motor Assembly, you must tighten in a CLOCKWISE pattern starting with
screw in lower left-hand side from spring.
Figure 2-23: VL3000 Tilt Motor Assembly Replacement
Tilt Motor
Head not shown for clarity.
NOTE:
Assembly
Spring
Sensor
Bracket
To Next Page
