09/2007
xiii
Phaser 8860/8860MFP Service Manual
System Configurations
Introduction
Initial Issue
System Configurations
Standard Features
The Phaser 8860/8860MFP offers these standard features:
• Maximum print speed (pages per minute) based on letter-size plain paper:
NOTE: Print speeds for media fed from Tray 1 may be up to 50% slower.
• First-page-out: 6 seconds for color prints, 15 seconds for color copies
• Copy, Print, Scan, Fax capabilities (options vary according to configuration and memory)
• Connections: USB, Ethernet 10/100 Base-Tx, Foreign Device Interface (available)
• RJ-11 Fax Modem (8860MFP only)
Available Configurations
Ta bl e 2 lists the standard configurations.
Product Options
Phaser 8860/8860MFP options include:
• Additional Trays
• Memory
•System Cart
Additional Trays
Trays 1 and 2 are standard on all configurations. The following additional tray combinations are
supported:
• One 525-Sheet Feeder (Tray 3)
• Two 525-Sheet Feeders (Trays 3 and 4)
Memory
All configurations have two memory slots supporting 256 MB, 512 MB, and 1 GB SODIMM
modules (up to maximum of 1 GB DDR2).
System Cart
The System Cart supports a fully-optioned system and provides space for media storage.
Metered Printing
Metered printing (PagePack), involves the combination of control software and specialized Ink
Sticks to meter system activity for billing purposes. The Configuration page lists Metered Ink as
Enabled when metering is enabled.
Metered Operation
When a metered printer is initialized at first power-up, the customer sets the printer to Metered
operation using a unique, factory-supplied, 4-digit PIN. Once set to Metered operation, the con-
trol software performs the following:
1. The Mode and PIN-entered values in Engine Control Board NVRAM are set.
2. The Control Panel momentarily displays “Metered Ink is now enabled”, then returns to
“Ready” (if no other errors).
3. The First Time Tips pages and the Configuration page are printed.
If an incorrect PIN is entered, “Incorrect numeric password” displays with a prompt “Retry” or
“Do not retry.” Retry returns to the enter prompt, “Do not retry” returns to the Replace Ink Stick
error message. The error persists until the correct PIN is entered.
NOTE: The Hidden Service menu provides an Enable Metered Ink option to restore the
Metered mode parameters to NVRAM should they become lost or corrupt.
Metered Ink
To support metered printing, metered Ink Sticks are available in all four colors. The shape of
the metered Ink Stick differs from the non-metered versions.
Table 1 Phaser 8860/8860MFP Print Speeds
Phaser 8860 Color Printer Phaser 8860MFP Multifunction Product
PostScript Print Quality Modes:
– Fast Color: 30 ppm
– Standard: 24 ppm
– Enhanced: 16 ppm
– High Resolution/Photo: 10 ppm
PostScript Print Quality Modes:
– Fast Color: 30 ppm
– Standard: 24 ppm
– Enhanced: 16 ppm
– High Resolution/Photo: 10 ppm
PCL Print Quality Modes:
– 300 x 600 dpi: 16 ppm
– 600 x 600 dpi: 8 ppm
PCL Print Quality Modes:
– 300 x 600 dpi: 16 ppm
– 600 x 600 dpi: 8 ppm
Table 2 Phaser 8860/8860MFP Configurations
Features 8860 8860MFP
Memory 256 MB 512 MB
Hard Drive No* Yes
Automatic 2-sided Printing (DADF) No Yes
525-Sheet Feeder No* No*
System Cart No* No*
Copy No Yes
Scan to PC No Yes
Scan to E-mail No Yes
Scan to Hard Drive No Yes
Fax No Yes
* This option can be purchased separately for this configuration.
